Terrier

General: Barrel grab for lifting, handling and transporting of (oil)drums, where the drums have to stay in a horizontal position.

  • Marking: Working load limit, jaw capacity and CE-marking.
  • Finish: Yellow painted.
  • Standard: EN 13155
  • Safety factor: 5:1.
TVKH_Blank
tvkh
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
Max. jaw opening (mm) U (mm) S (mm) V (mm) T (mm) X (mm) Y (mm) Weight
kg
CAD
16.01828100 TVKH 0.6 0-25 765 434 305 50 100 10 7

Download CAD
