General: Man riding baskets can be used quickly and safely for temporary working at heights. Our man riding baskets are designed to be hung from a crane hook.
Design: Welded frame in hollow beam with the bottom and sides covered in expanded-metal mesh. Personal items of safety equipment can be attached to the inside handrail. The basket is supported underneath for easy handling by truck or forklift. A gate is provided on one of the short sides (see the respective model). The basket is supplied complete with a four leg wire rope sling and a masterlink typ MLA.
BK-500: Supplied with inward-opening latching gate.
BK-1000: Supplied with inward-opening latching gate.
BK-1000E (Emergency): Identical to the BK-500 / BK-1000 above except that in an emergency the entire end gate can be opened outwards to provide access, eg, for a stretcher and medical equipment to be taken on board.
Proof: First inspection by accredited third party authority including certificate.
- Material: Hollow-beam and plate of high-strength structural steel.
- Marking: Sign according to standard for inspection mark.
- Finish: Yellow painted.
- Note: Before use basket and crane has to be initially inspected together.
Download CAD
Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
