Design:Bolt Type Anchor shackles with thin head bolt – nut with cotter pin. Meets
the performance requirements of Federal Specification R-C-271G, Type IVA, Grade B, Class 3, except for those provisions required of the contractor.
- Material: Forged Alloy Steel – Quenched and Tempered, with bow and bolt.
- Marking: According to standard, CE-marked, WLL.
- Finish: Hot dip galvanized.
- Standard: EN 13889
- Safety factor: 8
- Grade: 8
Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
