Design: Pressed of profile steel.

  • Finish: Galvanized.
Kaus2_e_225mm
thimble_din_6899
Select a row from the table below, then click the add to quote button
Part Code Wire Ø (mm) A
mm
C (mm) L (mm) B (mm) Weight CAD
10.2520000300 2,5 12 6,2 19 3 0.5
10.2520000400 3,5 13 7,2 21 4 0.8
10.2520000500 4 14 8,8 23 5 1
10.2520000600 5 16 11 25 6 1.6
10.2520000700 6 20 14 32 8 3
10.2520000800 7 24 16 38 10 4.7
10.2520001000 9 28 19 45 12 6.8
10.2520001200 11 32 22 51 14 10
10.2520001300* 12 36 24 58 16 15
10.2520001400 13 40 28 64 18 20
10.2520001600 15 45 32 72 20 29
