At least 25% greater WLL than traditional Grade 8 products.
Testing according to DIN PAS 1061 and ASTM A952/A 952M.
Proof Load tested at 2.5 times the WLL with certification for each batch.
Fatigue rated to 20,000 cycles at 1.5 times the WLL.
Enables full WLL while in use, thanks to supporting wings which prevent chain link deformation.
Extra safe pin.
- Material: Quenched and Tempered Alloy Steel.
- Marking: According to standard, Size, grade, manufacturer ID, traceability.
- Temperature range: -40ºC up to +200°C (without reduction in WLL).
- Finish: Blue painted.
- Standard: EN 1677-1
- Note: Not for use with Omega Link.
- Safety factor: 4:1
- Grade: 10
Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
