Svero
General: Low-built block trolley for hanging e.g. chain blocks and wire hoists. The trolley can be supplied with a load of 0.5 tons up to 5 tons. The trolley has corner protection which prevents the trolley from detaching from the beam and ball bearing wheels. It is easily adjustable by the left- and right-handed carrier bracket and fits most brands of hoists.

  • Marking: WLL, name plate and CE.
  • Finish: Black painted.
SVERO illu 21
E x available
SVERO 21 dwg
Select a row from the table below, then click the add to quote button
Part Code WLL
ton
Type Min curve r m A min-max B (mm) C (mm) Ø D (mm) E (mm) F (mm) G (mm) H (mm) Ø J mm Ø K (mm) L (mm) M (mm) Ø O mm P (mm) R (mm) Weight
kg
CAD
16.0521123A 0.5 21123A 1,25 50-160 212 20 70 88 20 56 35 32 19 264 130 100 24 104 14.3
16.05211245A 0.5 21124A 1,25 161-280 A+57 20 70 88 20 56 35 32 19 264 130 100 24 104 15.5
16.0521143A 1 21143A 1,25 50-160 212 20 70 88 20 51 40 32 24 264 130 100 24 104 14.3
16.0521144A 1 22144A 1,25 161-280 A+57 20 70 88 20 51 40 32 24 264 130 100 24 104 15.5
16.0521163A 2 21163A 1,80 64-180 248 24 100 120 24 63 51 40 32 335 165 100 31 118 25.3
16.0521164A 2 21164A 1,80 181-300 A+76 24 100 120 24 63 51 40 32 335 165 100 31 118 27.4
16.0521173A 3 21173A 2,20 74-180 262 28 114 137 30 78 57 46 35 380 180 165 37 130 38.2
16.0521174A 3 21174A 2,20 181-300 A+89 28 114 137 30 78 57 46 35 380 180 165 37 130 41.2
16.0521193A 5 21193A 2,50 82-180 270 34 140 166 32 92 64 56 42 437 215 205 41 132 56.7
16.0521194A 5 21194A 2,50 181-300 A+97 34 140 166 32 92 64 56 42 437 215 205 41 132 60.4
