Weld-on Point 8-057

The eyes can be loaded with working load limit in all directions, pivots through 180°. Load rated parts are 100% magnaflux crack detected.
Individual forged parts are traceable to Test Certification.
Proof tested to 2.5 times the WLL, fatigue rated to 1.5 times the WLL.
A protected spring keeps the load ring in a required position. The parts are connected in such a way that they remain captive. The spring also reduces noise caused by vibration.

  • Material: Manufactured from forged alloy steel, quenched and tempered.
  • Marking: According to standard, CE-marked, WLL, size, steel quality, manufacturer ID and traceability.
  • Standard: EN 1677-1

After click on the “Show table” button, you will see the table with all technical details about the product.

Filters

Show more filters

Select the variant of your choice. Add it in the cart for purchase or request quotation.
