General: For lifting of concrete plates type HDF i a horisontal position and for standard HDF-plates of 1200 mm in width. The HDF-lifter can be used as a single lifter or in pair together with a spreader beam. Easy opened by the handle and automatic locking when fitted to the concrete plate. Dilivered with security chain to be used with the clamp.


  • Material: Plate of high strength structural steel.
  • Marking: WLL and CE-marking.
  • Finish: Yellow painted.
betongsax
betongsax_complete_new
DSC_0111
Betongsax_m
Select a row from the table below, then click the add to quote button
Part Code WLL
ton
L
mm
b
mm
H
mm
K
mm
Weight
kg
CAD
HDF-600 2.75 1180-1235 600 350-440 1130-1143 180
HDF-1250 3.5 1180-1235 1,250 350-440 1130-1143 210
HDF-2000 5 1180-1235 2,000 350-440 1130-1143 260

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.

Get CAD
Download
