General: A self locking beam trolley unit with wheel guarding anti-drop plates. Designed for maximum speed of application, minimum maintenance requirements and maximum safety.
Proof load: 2 x WLL.





  • Finish: Yellow painted.
  • Note: All WLL apply to vertical lifting only.
  • Safety factor: 5:1.
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
Grab width A B
mm
T
mm
C
mm
Weight
kg
CAD
16.05A1 A1 3 76-203 28 135 30 32
16.05A2 A2 6 100-305 30 130 40 33
16.05A3 A3 10 100-305 30 140 40 48
