• Not for lifting

Design: Forged.

  • Material: Stainless acid proof steel. AISI 316.
  • Finish: Polished.
  • Warning: Not approved for lifting.
101-r_e_225mm
2929_lom_b_225mm
Select a row from the table below, then click the add to quote button
Part Code Code Pin diameter
mm
Thread d1 A
mm
c*
mm
D
mm
11.559003S 9003-S 8 M8 16 32 8
11.559004S 9004-S 10 M10 20 40 10
11.559006S 9006-S 12 M12 25 48 12
11.559008S 9008-S 16 M16 32 64 16
11.559009S 9009-S 20 M20 38 76 19
11.559010S 9010-S 22 M22 44 85 22
**Tolerance: +/- 5%
