General: For handling of horizontal or upright board materials. By repositioning the 4-legged lifting sling, the board material can be raised from a horizontal to an upright position. When upright boards are handled, the projecting part of the board functions as a support in a window or door opening.
Design: The incorporation of a counterbalance in the design makes the fork self-balancing, which means that no repositioning is needed for lifting horizontal boards or empty forks. Board forks are equipped with additional lifting lugs for horizontal handling of boards that are smaller than the respective maximum width. The 6092 model has extra thin forks (size S).


Proof: Batch proof 1,5 x WLL.


Accessories: 4-leg lifting sling with safety hooks.

  • Material: Hollow-beam and plate of high-strength structural steel. Support board of spruce plywood.
  • Marking: Working load limit, dead weight and CE marking.
  • Finish: Yellow painted.
Skiv_e_225mm
Special_Wood_Lifter_1.6-tons_1
Special_Wood_Lifter_1.6-tons_2
Skivm_new_225mm
Currently this product cannot be added to an online quote. Please contact us directly for enquires.
Art No
Code
Max
load
Max board
width
Extra eyes for
board width
A
E
H
L
S
Weight
Price
Price


tons
mm
mm





Kg
code
sek/pc
06.306091
6091
1,3
900
600
1500
930
630
2000
50
150
F3
12570,00
06.306092
6092
1,6
1200
900/600
1520
1230
630
2000
40
260
F3
16395,00
Other sizes and design available on request.















Lifting sling for fork

Art No
Code
Length
Type of sling
Master link
Hook


m
mm
code
code
11.90KL4SKI
KL-4.SKIV
1,5
Chain Ø 6
MLAC-6-8
SH-5/6-8
10.74LS4SKI
LS-4.SKIV
1,5
Steel wire rope Ø 10
MLA-7-8
SH-5/6-8
*Maximum load is valid at a maximum lifting angle (ß) of 45º.





Other sizes and design available on request.
