General: For handling of horizontal or upright board materials. By repositioning the 4-legged lifting sling, the board material can be raised from a horizontal to an upright position. When upright boards are handled, the projecting part of the board functions as a support in a window or door opening.
Design: The incorporation of a counterbalance in the design makes the fork self-balancing, which means that no repositioning is needed for lifting horizontal boards or empty forks. Board forks are equipped with additional lifting lugs for horizontal handling of boards that are smaller than the respective maximum width. The 6092 model has extra thin forks (size S).


Proof: Batch proof 1,5 x WLL.


Accessories: 4-leg lifting sling with safety hooks.

  • Material: Hollow-beam and plate of high-strength structural steel. Support board of spruce plywood.
  • Marking: Working load limit, dead weight and CE marking.
  • Finish: Yellow painted.
