Pallet fork for handling of standard pallets from the long side.
Design: Thanks to the spring-loaded lifting eye, the pallet fork is self-balancing, which means that the forks are always horizontal, regardless of whether the pallet fork is empty or loaded. Please note the minimum load specified in the table. Concealed spring and linkage.
Proof: Batch proof 2 x max load.

Material: Beam and plate of high-strength structural steel.
Marking: Minimum load, maximum load and CE-marking.
Finish: Yellow painted.
Note: :Other sizes and designs are available upon request. For custom made forks the type has some restrictions regarding small loads and low profile goods (measure H).

Pallet Fork Type 6020F

Select a row from the table below, then click the add to quote button

Part Code	Code	WLL ton	Min load kg	Tp max* mm	A mm	E mm	H mm	L mm	S mm	Weight kg
13.306022F	6022-F	1.5	300	500	700	980	1,500	485	50	86
13.306020F	6020-F	2	300	400	700	800	1,500	485	50	80
13.306023F	6023-F	2.5	300	500	700	980	1,500	515	60	100
13.306021F	6021-F	3	300	400	700	800	1,500	515	60	92

*The "Tp max" value is valid for maximum load. The pallet forks can be used with a greater point of balance if the load is reduced.
