• Not for lifting
  • Ordinary right hand lay
  • Stainless

Typical applications: Rigging, stays, controls and signalling devices.

  • Material: AISI 316.
  • Marking: According to standard
  • Standard: EN 12385-4
  • Fill factor: 0.55
  • General use Wire for general use
  • Stay rope Stay rope
Select a row from the table below, then click the add to quote button
Part Code Rope diameter
mm
Steel Area
mm²
Min. breaking force
kN
1570 N/mm²
Weight
kg/100m
01.S10049010D 1 0,43 0,61 0,38
01.S10049015D 1,5 0,97 1,37 0,86
01.S10049020D 2 1,73 2,44 1,54
01.S10049025D 2,5 2,7 3,81 2,4
01.S10049030D 3 3,89 5,48 3,46
01.S10049040D 4 6,91 9,75 6,14
01.S10049050D 5 10,8 15,2 9,6
01.S10049060D 6 15,6 21,9 13,8
01.S10049070D 7 21,2 29,8 18,8
01.S10049080D 8 27,6 39 24,6
