General: The lifting equipment is designed for horizontal lifting of one or more plates of the same width. The equipment consists of two fork lifters and a 4-leg chain sling. Always delivered complete.
Design: Cut reinforced plate forks together with weld assembled pipes gives optimal dimensioning and low weight. The geometry is adjusted to prevent the forks tilting from the plate as long as the minimum lift height is followed according to the table.
Proof: Batch proof 1,5 x WLL.
- Material: Plate and pipe of high-strength structural steel
- Marking: CE-marked, Badge with Type, WLL, maximum plate width
- Finish: Yellow painted
- Warning: We recommend other lifting equipment for thin plates that can bend during the lift.
Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
