General: The lifting equipment is designed for horizontal lifting of one or more plates of the same width. The equipment consists of two fork lifters and a 4-leg chain sling. Always delivered complete.
Design: Cut reinforced plate forks together with weld assembled pipes gives optimal dimensioning and low weight. The geometry is adjusted to prevent the forks tilting from the plate as long as the minimum lift height is followed according to the table.
Proof: Batch proof 1,5 x WLL.

Material: Plate and pipe of high-strength structural steel
Marking: CE-marked, Badge with Type, WLL, maximum plate width
Finish: Yellow painted
Warning: We recommend other lifting equipment for thin plates that can bend during the lift.

Select a row from the table below, then click the add to quote button

Part Code	Code	WLL	Plate width mm	chain Ø mm	Min lift height H at max plate width B B=1000	Min lift height H at max plate width B B=1500	Min lift height H at max plate width B B=2000	A mm	C mm	E mm	L mm	M mm	Weight kg
16.81PPL010010	PPL-1	1	1,000	6	1,300			80	24	25	150	1,000	11
16.81PPL010015	PPL-1	1	1,500	6		1,700		80	24	25	150	1,000	11
16.81PPL010020	PPL-1	1	2,000	6			2,200	80	24	25	150	1,000	11
16.81PPL020010	PPL-2	2	1,000	7	1,300			80	31	25	175	1,000	16
16.81PPL020015	PPL-2	2	1,500	7		1,700		80	31	25	175	1,000	16
16.81PPL020020	PPL-2	2	2,000	7			2,200	80	31	25	175	1,000	16
16.81PPL030010	PPL-3	3	1,000	7	1,500			90	36	35	200	1,000	25
16.81PPL030015	PPL-3	3	1,500	7		1,800		90	36	35	200	1,000	25
16.81PPL030020	PPL-3	3	2,000	7			2,300	90	36	35	200	1,000	25
16.81PPL040020	PPL-4	4	2,000	8				90	36	40	200	1,000	29
16.81PPL040015	PPL-4	4	1,500	8		1,800	2,300	90	36	40	200	1,000	29
16.81PPL040010	PPL-4	4	1,000	8	1,500			90	36	40	200	1,000	29
16.81PPL050010	PPL-5	5	1,000	10	1,500			90	45	40	200	1,000	40
16.81PPL050015	PPL-5	5	1,500	10		1,800		90	45	40	200	1,000	40
16.81PPL050020	PPL-5	5	2,000	10			2,300	90	45	40	200	1,000	40
16.81PPL080010	PPL-8	8	1,000	10	1,500			90	45	50	200	1,250	43
16.81PPL080015	PPL-8	8	1,500	10		1,800		90	45	50	200	1,250	43
16.81PPL080020	PPL-8	8	2,000	10			2,300	90	45	50	200	1,250	43
16.81PPL100010	PPL-10	10	1,000	13	1,500			150	45	65	200	1,250	70
16.81PPL100015	PPL-10	10	1,500	13		1,800		150	45	65	200	1,250	70
16.81PPL100020	PPL-10	10	2,000	13			2,300	150	45	65	200	1,250	70

*The specified weight is without the chain sling.Other dimensions and designs available upon request.

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.

Get CAD
